Yantai Xinglong Pressure Vessel Manufacturing Co., Ltd.；

A: Our air receiver tanks are available in multiple pressure ratings:

● Low Pressure: Up to 10 bar (145 PSI) - suitable for general manufacturing

● Medium Pressure: 10-16 bar (145-232 PSI) - standard industrial operations

● High Pressure: 16-30 bar (232-435 PSI) or higher - specialized applications like PET bottle blowing, laser cutting

Custom pressure ratings can be manufactured according to your specific requirements

A: We manufacture air receiver tanks with capacities ranging from 50 liters to 75,000 liters (approximately 13 to 19,800 gallons). Common sizes include 100L, 200L, 300L, 500L, 1000L, 2000L, 3000L, and larger custom volumes. Both vertical and horizontal orientations are available.

A:Vertical Tanks: Save floor space, better condensate drainage due to gravity, easier installation in compact areas. Recommended for limited space installations.

Horizontal Tanks: Lower center of gravity, easier maintenance access, suitable for outdoor installation or when ceiling height is restricted.

Choice depends on your facility layout, space constraints, and installation preferences.

A: Our air receiver tanks hold multiple international certifications:

ASME U‑Stamp (American Society of Mechanical Engineers) ‑ Required for North American market

CE Marking with PED Certification (Pressure Equipment Directive 2014/68/EU) ‑ Mandatory for European Union

ISO 9001:2015 Quality Management System

Additional certifications available: TUV, UL, CRN (Canada), and other regional standards upon request

ASME Certification: Follows ASME Boiler and Pressure Vessel Code (BPVC), primarily required for the US, Canada, and some Asian markets. Focuses on design, manufacturing, inspection, and testing standards. Requires authorized inspector involvement and U‑stamp application.

CE/PED Certification: Complies with EU Pressure Equipment Directive 2014/68/EU. Equipment with maximum allowable working pressure >0.5 bar must comply. Classification into Category I‑IV based on pressure and volume, with different conformity assessment modules.

Products can be dual‑certified (both ASME U‑stamped and CE‑marked) for global market access.

A: Yes, each shipment includes complete certification documentation:

‑ Certificate of Conformity

‑ Material Test Certificates (MTC)

‑ Hydrostatic Test Reports

‑ Non‑Destructive Testing (NDT) Reports (if applicable)

‑ Welding Procedure Qualification Records

‑ Third‑party inspection certificates (ASME/CE/TUV as required)

‑ User manual and installation guide

All documents are provided in English and can be legalized/notarized if required by your country's customs.

A: Every air receiver tank undergoes rigorous quality testing:

‑ Hydrostatic Pressure Test: Tested at 1.5 times the design pressure to verify structural integrity and leak tightness

‑ Non‑Destructive Testing (NDT): Ultrasonic testing (UT), radiographic testing (RT), or magnetic particle inspection (MPI) for weld joints

‑ Visual Inspection: Surface quality, dimensions, and marking verification

‑ Material Verification: Chemical composition and mechanical properties testing

‑ Pressure Relief Valve Testing: Functional test of safety devices

Test reports are issued for each unit and included in shipment documentation.

A: Absolutely. We welcome and facilitate third‑party inspections from recognized agencies such as:

SGS, Bureau Veritas, Intertek, TÜV Rheinland

Customer‑appointed inspectors

Insurance company surveyors

Inspection can cover visual examination, dimensional checks, witness hydrostatic testing, review of documentation, and packaging verification. Please notify us at least 7 days before the planned inspection date.

A: Yes, we provide both OEM and ODM services:

OEM (Original Equipment Manufacturing): You provide complete design drawings, specifications, and technical requirements. We manufacture according to your exact specifications with your brand/logo.

ODM (Original Design Manufacturing): We provide design support and engineering expertise. You specify functional requirements, and our team develops the product design, which can be customized with your branding.

Both options include custom port configurations, special coatings, unique dimensions, and branded nameplates.

A: MOQ varies by product type and customization level:

‑ Standard Models: MOQ as low as 1‑5 units for regular specifications

‑ Custom Specifications: Typically 10‑20 units depending on complexity

‑ Fully Customized ODM: Usually 20‑50 units to optimize production efficiency

For first‑time cooperation, we can accept smaller trial orders to build mutual trust. Sample orders are also available for quality evaluation.

A: Lead times depend on order quantity and customization:

‑ Standard Products in Stock: 3‑7 days

‑ Regular Custom Orders: 15‑25 days after deposit confirmation

‑ Large Volume or Complex Customization: 30‑45 days

‑ Peak Season Considerations: Add 5‑10 days during Chinese New Year or Golden Week holidays

We maintain transparent communication throughout production and can expedite urgent orders with additional costs (overtime or air freight for materials).

A: Yes, we offer sample units for quality evaluation:

‑ Sample cost is charged at regular unit price

‑ Sample production time: 7‑10 days

‑ Shipping cost borne by customer (or collect on delivery)

‑ Sample cost can be refunded or deducted from subsequent bulk order

This allows you to verify material quality, workmanship, certification compliance, and performance before committing to large orders.

A: Export packaging follows international standards:

‑ Surface Protection: Anti‑rust oil coating + plastic film wrapping

‑ Structural Support: Steel frame crating or wooden pallets with steel strapping

‑ Moisture Protection: Desiccant bags inside packaging

‑ Marking: Clear labeling with product specs, handling instructions, and shipping marks

‑ Container Loading: Professional lashing and blocking to prevent movement during transit

For FCL (Full Container Load), tanks are directly secured in containers. For LCL (Less than Container Load), additional protective crating is applied.

A: Each air receiver tank is equipped with essential safety components:

‑ Safety Relief Valve: Set at 10% above maximum working pressure, prevents overpressure

‑ Pressure Gauge: Dial graduated to at least 1.2 times the safety valve setting pressure

‑ Drain Valve: Manual or automatic bottom drain for condensate removal

‑ Nameplate: Displays design pressure, test pressure, capacity, serial number, and certification marks

‑ Inlet/Outlet Ports: Configured per customer specification (flanged or threaded)

Additional accessories available: moisture separator, pressure switch, isolation valves, and instrumentation connections.

A: Yes, comprehensive installation support includes:

‑ Detailed Installation Manual: Step‑by‑step instructions with diagrams (English version)

‑ Video Tutorials: Available on request for complex installations

‑ Remote Technical Support: Video call assistance during installation

‑ On‑site Commissioning: Engineer dispatch available for large projects (travel costs borne by customer)

Key installation considerations:

‑ Ensure proper foundation with adequate load‑bearing capacity

‑ Maintain minimum clearance for maintenance access

‑ Install in well‑ventilated area away from heat sources

‑ Connect safety valve discharge pipe to safe location

‑ Perform initial pressure test before full operation

A: Standard warranty terms:

‑ Main Pressure Vessel Body: 2 years from delivery date against manufacturing defects

‑ Accessories (valves, gauges, fittings): 1 year

‑ Extended Warranty: Available upon request for additional fee

Warranty covers material defects and workmanship issues under normal operating conditions. Does not cover damage from improper installation, misuse, unauthorized modifications, or force majeure events.

A: We ensure reliable spare parts availability:

‑ Common Parts Inventory: Safety valves, pressure gauges, drain valves kept in stock

‑ Fast Delivery: Standard parts shipped within 3‑5 days via express courier

‑ Custom Parts: Manufactured within 10‑15 days if not in stock

‑ Long‑term Support: Guaranteed parts supply for 10+ years after product discontinuation

‑ Competitive Pricing: Spare parts offered at reasonable rates, not inflated

We recommend purchasing a basic spare parts kit with initial order for critical components.

A: Yes, comprehensive after‑sales technical support includes:

‑ 24/7 Email Support: Response within 24 hours

‑ Phone/Video Consultation: Available during business hours (GMT+8)

‑ Troubleshooting Guides: Detailed manuals for common issues

‑ Maintenance Schedules: Recommended inspection and service intervals

‑ Operator Training: Online training sessions available

For complex technical issues, our engineering team can provide remote diagnosis and solution recommendations.

A: Regular maintenance ensures safe and efficient operation:

‑ Daily: Check pressure gauge reading, inspect for leaks, drain condensate

‑ Weekly: Visual inspection of exterior, check safety valve functionality

‑ Monthly: Inspect mounting bolts, verify nameplate legibility, check corrosion protection

‑ Annually: Professional inspection, hydrostatic re‑test if required by local regulations, NDT of critical welds

‑ Every 5 Years: Mandatory hydrostatic re‑testing per most international standards

Keep detailed maintenance records for warranty claims and regulatory compliance.

A: Yes, we provide regulatory compliance support:

‑ Documentation Package: Complete technical files meeting international standards

‑ Local Certification Guidance: Advice on country‑specific registration requirements

‑ Notarization/Legalization: Assistance with document authentication for customs

‑ Technical Liaison: Direct communication with your local inspection agency if needed

However, final compliance responsibility rests with the importer. We recommend consulting with local pressure vessel authorities before importation to confirm specific requirements.
